MOTEE Square Photoelectric Near Infrared Sensor EZ Diffuse Reflection Strip Light Optical Sensor

Stable 5x30mm strip beam design for detection.

Built-in BG function, especially suitable for detecting products with hollow or uneven surfaces.

Intuitive high-brightness red light with high-speed response.

Default cable length is 2 meters, customization available.

Description

NPN signal output	EZ-D461	EZ-D561
PNP signal output	EZ-D461P	EZ-D561P
Detection distance	5mm-200mm, spot size 4mm	5mm-100mm, spot size 1mm
Light source	640nm red light	640nm laser
Minimum detectable object	2mm copper wire (set distance 100mm), can filter up to 5mm gap or perforation
Repeatability	Less than 1mm
Supply voltage	12-24V DC±10%
Pulse	P-P10% or less
Current consumption	13mA or less
Short circuit protection	Equipment
Output	Default NPN signal, maximum inflow current: 50mA
	Applied voltage: 30V DC or less (between output and 0V)
	Residual voltage: 2V or less (inflow current 50mA)
Reaction time	0.5ms or less
Working status indicator	Power on green LED, sensing orange LED (lit when output is ON)
Protective structure	IP67(IEC)
Operating ambient temperature	-25 to +55°C (no condensation or freezing), storage: -30 to +70°C
Operating environment humidity	35-85%RH, Storage: 35-85%RH
Ambient illumination	Incandescent lamp: illumination of the light receiving surface is less than 3,000R
Light projector	640nm Red LED
Material	PC
Cable	2.8mm outer diameter rubber cable, 2m long, can be customized to extend
Wight	50g
