MOTEE for M18 24V DC Inductive Proximity Sensor Switch Long Distance Metal Position Sensor

Operating Voltage: 5~24VDC

Connection Method: 3-core cable, 2.8mm diameter; 3 meters long

Position Repeatability: ±0.001mm

Withstand Voltage: AC1000V for 1 minute

Description

Product Model	MD +LV83BN	MD+LV83BP
Output	NPN.NO	PNP.NO
Operating voltage	5~24VDC	5~24VDC
Connection	3-core cable diameter 2.8mm; cable length 3 meters
Position repeatability	±0.001mm
Journey	3mm
Operational force	0.6N
Mobile PT before action	0.5~0.9mm
Hysteresis MD	0.1mm or less
Action frequency	120 times/minute
Output Current	10mA
Indicator Lights	The light is on when output
Compressive strength	AC1000V 1 minute
Dielectric strength	250VDC≥20MΩ
Ambient temperature and humidity	20°C~+85°C (no freezing) 20%~95%RH (no condensation)
Install	M8 nut installation torque 5N·m
Protection level	IP67
